JVC DLA-RS500

The DLA-RS500 is JVC's high performance fully-customizable home cinema projector. It produces exquisite quality images with JVC's exclusive 4K e-shift4. It accepts native 4K 60P (4:4:4) material through Full Speed 18Gbps HDMI/HDCP 2.2 compatible inputs and displays it with stunning 3840 x 2160 precision and unbeatable contrast and clarity. JVC's exclusive D-ILA technology delivers a class leading 120,000:1 Native Contrast Ratio for images that pop off the screen. For 2016, JVC projectors include HDR content compatibility and an improved Clear Motion Drive for unmatched picture quality, as well as a newly developed high power lamp that provides 1800 lumens—the highest in-class brightness.

The DLA-RS500 is THX Certified and meets or exceeds the industry's highest standards. It is clearly the best value in a totally customizable 4K home theater projector.

Extraordinary Picture Quality

• 1800 Lumens with High Power Lamp (PK-L2615U) —NEW for 2016
  265W High / 200W Normal
• 120,000:1 Native Contrast Ratio
• Intelligent Lens Aperture increases dynamic contrast ratio to 1,200,000:1
• 6th generation 0.7-inch D-ILA devices
• e-shift4 4K Precision 3840 X 2160 Projected Image —Upgraded feature
• Dual Full Speed 18Gbps HDMI/HDCP 2.2 Compatible Inputs —Upgraded feature
  • Compatible with full spec native 4K signals such as 4K60p 4:4:4 4K60p 4:2:2/36bit and 4K24p 4:4:4/36bit
  • Compatible with 4K streaming devices and UHD BD content
  • Compatible with DCI Color Space
• HDR (High Dynamic Range) Compatible —NEW for 2016!
• Multi Pixel Control (MPC) with Auto Mode for ease of use —Improved
  MPC works with 4K60P (up to 4:4:4) signals
• Clear Black processing (Patent pending)
• Motion Enhance (2D, 3D, 4K) with Clear Motion Drive —Upgraded
• THX® 3D Certified
• ISF (Imaging Science Foundation) Licensed— Quality installers can calibrate projector to your room

Highly customizable

• sRGB, DCI and x.v. Color space
• Darkness and lightness correction
• Lens memory function memorizes 10 positions for focus, zoom and shift.
  Maintains constant height for 2.35, 1.85, 1.78 on same screen.
• Screen Mode Presets for different screen material (117 memory positions)
• Convergence Correction - 1/16th Pixel Increments (2 memory positions)
• Simplified 6-Axis Color Management System —NEW for 2016
• Manual Gamma Control included with JVC Calibration Software 6 —NEW for 2016
• Control4 SDDP (Simple Device Discovery Protocol) —NEW for 2016

Stunning 3D Performance with RF active shutter glasses (optional)

• Advanced 3D Crosstalk Cancellation Control
• 3D Anamorphic Mode
• Parallax adjustment for fine tuning 3D effect
• Accepts all modern 3D formats (Blu-ray, side-by-side, top-and-bottom)

Optimum Flexibility and Convenience

• Remote control via LAN, RS-232C, IR
• 12V Screen Trigger Output
• V: 80%/H: 34% motorized lens shift
• 1.4:1 to 2.8:1 lens throw
• 3 Year Warranty

*1 Resolution is 1920 X 1080 in 3D mode.
*2 Measurement, Measuring conditions, and method of notation all comply with ISO 21118
*3 When the video input signal is 4096x2160, data above 3840 is cropped equally on the left & right.
